Dell Optiplex 7090 Ultra Specs

Here's what you need to know about Dell Optiplex 7090 Ultra Specs, including price, processors, memory, graphics, storage, ports, and more.

Dell Optiplex 7090 Ultra Specs

The 2021 Dell Optiplex 7090 Ultra features 28W 11th Generation Intel Tiger Lake UP3 dual-core Intel Core i3-1115G4 up to a 28W quad-core Intel Core i7-1185G7 with a boost speed up to 4.80 GHz. The Tiger Lake PCH-LP (Integrated with the processor) motherboard inside Dell Optiplex 7090 Ultra has two memory slots that support up to 64GB of 3200MHz dual-channel DDR4 memory.

What's New in Dell Optiplex 7090 Ultra

Here's what you need to know about the Dell Optiplex 7090 Ultra.

  • Intel Tiger Lake PCH-LP Chipset.
  • 11th Gen Intel Tiger Lake Processors.
  • Up to Intel® Core™ i7-1185G7 (4C/8T, 3.00 → 4.80 GHz, 12MB SmartCache, 28W)
  • Up to 64GB 3200 MHz dual-channel DDR4 memory
  • Up to 2 x 2TB PCIe Gen 4 x4 NVMe SSD.
  • Up to 2TB 2.5" HDD.
  • 90W Power Adapter.
  • Up to Wi-Fi 6 and Bluetooth 5
  • More Features
    • Up to three display outputs (2 x USB-C Alt-Mode + DP).

Dell Optiplex 7090 Ultra Full Specifications

Dell Optiplex 7090 Ultra image
Dell Optiplex 7090 Ultra

Availability

Released2021
Release InfoAnnounced on May 11, 2021.
Pricing
  • $1,138.57
    i5-1115G4 4GB 500GB 2.5” Wi-Fi 5
  • $1,398.57
    i5-1145G7 8GB 256GB M.2 Wi-Fi 6
  • $1,470.00
    i5-1145G7 16GB 256GB M.2 Wi-Fi 6
  • $1,712.86
    i5-1185G7 16GB 256GB M.2 Wi-Fi 6
  • $1,855.00
    i5-1145G7 4GB 128GB M.2 Wi-Fi 6 C2422HE Monitor
Generations
Dell Optiplex 7090 Ultra Desktop Price
Dell OptiPlex 7000 7090 Ultra Desktop Computer - Intel Core i7 11th Gen i7-1185G7 Quad-core (4 Core) - 16 GB RAM DDR4 SDRAM - 256 GB M.2 PCI Express NVMe SSD - Mountable
Dell OptiPlex 7000 7090 Ultra Desktop Computer - Intel Core i7 11th Gen i7-1185G7 Quad-core (4 Core) - 16 GB RAM DDR4 SDRAM - 256 GB M.2 PCI Express NVMe SSD - Mountable
By Dell
$636.74
Was: $787.02
Dell OptiPlex 7000 7090 Ultra Desktop Computer - Intel Core i5 11th Gen i5-1145G7 Quad-core (4 Core) - 16 GB RAM DDR4 SDRAM - 256 GB M.2 PCI Express NVMe SSD - Mountable
Dell OptiPlex 7000 7090 Ultra Desktop Computer - Intel Core i5 11th Gen i5-1145G7 Quad-core (4 Core) - 16 GB RAM DDR4 SDRAM - 256 GB M.2 PCI Express NVMe SSD - Mountable
By Dell
$680.29
Dell Optiplex 7000 7090 Ultra Desktop (2021) | Core i7-512GB SSD - 8GB RAM | 4 Cores @ 4.4 GHz - 11th Gen CPU Win 11 Pro (Renewed)
Dell Optiplex 7000 7090 Ultra Desktop (2021) | Core i7-512GB SSD - 8GB RAM | 4 Cores @ 4.4 GHz - 11th Gen CPU Win 11 Pro (Renewed)
By Dell
$559.00
Dell 2021 OptiPlex 7090 Ultra Desktop - Intel Core i7 11th Gen - i7-1185G7 - Quad Core 4.4Ghz - 256GB SSD - 16GB RAM - Windows 10 Pro (Renewed)
Dell 2021 OptiPlex 7090 Ultra Desktop - Intel Core i7 11th Gen - i7-1185G7 - Quad Core 4.4Ghz - 256GB SSD - 16GB RAM - Windows 10 Pro (Renewed)
By Dell
$750.00
Dell OptiPlex 7000 7090 Ultra Desktop (2021) | Core i7-2TB HDD - 8GB RAM | 4 Cores @ 4.4 GHz - 11th Gen CPU Win 11 Pro (Renewed)
Dell OptiPlex 7000 7090 Ultra Desktop (2021) | Core i7-2TB HDD - 8GB RAM | 4 Cores @ 4.4 GHz - 11th Gen CPU Win 11 Pro (Renewed)
By Dell
$599.00
2021 Dell OptiPlex 7090 Ultra Desktop - Intel Core i3 11th Gen - i3-1115G4 - Dual Core 4.1Ghz - 256GB SSD - 8GB RAM - Windows 10 Pro (Renewed)
2021 Dell OptiPlex 7090 Ultra Desktop - Intel Core i3 11th Gen - i3-1115G4 - Dual Core 4.1Ghz - 256GB SSD - 8GB RAM - Windows 10 Pro (Renewed)
By Dell
$489.00

Exterior

Dell Optiplex 7090 Ultra
Dimensions3.78” x 10.09” x 0.78” (96.1 x 256.2 x 19.7 mm)
WeightStarting at 1.16 lb (0.525 kg)
Colors
Black
Keyboard and Trackpad
  • Dell Pro Wireless Keyboard and Mouse - KM5221W - English
  • Dell KB522 Business Multimedia Keyboard (US)
  • Dell KB813 Smart Card Keyboard (US)
  • Dell KB216 Wired Keyboard English
  • No Keyboard
PortsBottom
  • 1 x USB-C
    USB 3.2 Gen 2 with DisplayPort Alt Mode and Power Delivery.
  • 2 x USB-A
    USB 3.2 Gen 2 (10 Gbps) with Smart Power On.
  • 1 x DisplayPort 1.4
  • 1 x RJ45
    Gigabit Ethernet port.
  • 1 x DC-in
    4.5mm barrel type.
Left
  • 1 x Thunderbolt 4
    USB 4 with DisplayPort Alt Mode.
  • 1 x USB-A
    USB 3.2 Gen 2 (10 Gbps) with PowerShare.
  • 1 x Universal Audio Jack
Right
  • 1 x Kensington Slot
  • 1 x Security Screw Slot

Chasis

Dell Optiplex 7090 Ultra
Form FactorUltra Form Factor
Power Supply90W
4.5mm Barrel Power Adapter.

Internal Specs

Dell Optiplex 7090 Ultra
ChipsetTiger Lake PCH-LP (Integrated with the processor)
Processor
Integrated Graphics
  • 11th Gen Intel® Core™ i3-1115G4
    Intel® UHD Graphics
    48 Execution Units, 400 → 1250 MHz
  • 11th Gen Intel® Core™ i5-1145G7
    Intel® Iris® Xe Graphics
    80 Execution Units, 400 → 1300 MHz
  • 11th Gen Intel® Core™ i7-1185G7
    Intel® Iris® Xe Graphics
    96 Execution Units, 400 → 1350 MHz
Memory
  • Memory Slots: 2 SODIMM slots
  • Memory Type: Single or Dual Channel DDR4 Memory
  • Memory Speed:
    3200MHz
Memory Configurations
4GB 8GB 16GB 32GB 64GB
Storage
  • 256GB 512GB 1TB 2TB
    M.2 PCIe Gen 3 x4 or Gen 4 x4 NVME SSD
  • 500GB 1TB 2TB
    5400 rpm or 7200 rpm 2.5" SATA Hard Drive
SlotsExpansion Slots
  • No Expansion slot.
SATA
  • 1 x SATA 3.0 FFC connector
    For 2.5-inch 7mm slim HDD/SSD.
M.2
  • 1 x M.2 2230 slot
    For WiFi and Bluetooth combo card
  • 1 x M.2 2230 slot
    For PCIe SDD.
  • 1 x M.2 2230/2280 slot
    For SSD/Intel Optane

Connectivity

Dell Optiplex 7090 Ultra
Wi-Fi
  • Qualcomm QCA61x4a
    Up to 867 Mbps Dual band 2.4 GHz/5 GHz WiFi-5 (802.11ac) Bluetooth 5.0
  • Intel AX201
    Up to 2400 Mbps Dual band 2.4 GHz/5 GHz WiFi-6 (802.11ax) Bluetooth 5.1
Bluetooth
Bluetooth 5.0 Bluetooth 5.1
EthernetIntel i219LM Gigabit Ethernet controller
Speed: 10/100/1000 Mbps.

Software

Dell Optiplex 7090 Ultra
OS
  • Windows 10 Home Windows 10 Pro
    Upgradable to Windows 11
  • Ubuntu Linux 20.04 LTS
Built-in Apps
Microsoft Office 30 Day Trial

Camera & Audio

Dell Optiplex 7090 Ultra
Audio
  • No built-in Speaker
  • Audio controller
    • Realtek ALC3204-CG
    • Intel High Definition Audio
  • External Ports
    • 1 x Universal Audio Jack
      Front

Misc

Dell Optiplex 7090 Ultra
Warranty3-Year Basic Onsite Service

Dell Optiplex 7090 Ultra Price

Here is the latest price update for Dell Optiplex 7090 Ultra.

Dell Optiplex 7090 Ultra Desktop Price
Dell OptiPlex 7000 7090 Ultra Desktop Computer - Intel Core i7 11th Gen i7-1185G7 Quad-core (4 Core) - 16 GB RAM DDR4 SDRAM - 256 GB M.2 PCI Express NVMe SSD - Mountable
Dell OptiPlex 7000 7090 Ultra Desktop Computer - Intel Core i7 11th Gen i7-1185G7 Quad-core (4 Core) - 16 GB RAM DDR4 SDRAM - 256 GB M.2 PCI Express NVMe SSD - Mountable
By Dell
$636.74
Was: $787.02
Dell OptiPlex 7000 7090 Ultra Desktop Computer - Intel Core i5 11th Gen i5-1145G7 Quad-core (4 Core) - 16 GB RAM DDR4 SDRAM - 256 GB M.2 PCI Express NVMe SSD - Mountable
Dell OptiPlex 7000 7090 Ultra Desktop Computer - Intel Core i5 11th Gen i5-1145G7 Quad-core (4 Core) - 16 GB RAM DDR4 SDRAM - 256 GB M.2 PCI Express NVMe SSD - Mountable
By Dell
$680.29
Dell Optiplex 7000 7090 Ultra Desktop (2021) | Core i7-512GB SSD - 8GB RAM | 4 Cores @ 4.4 GHz - 11th Gen CPU Win 11 Pro (Renewed)
Dell Optiplex 7000 7090 Ultra Desktop (2021) | Core i7-512GB SSD - 8GB RAM | 4 Cores @ 4.4 GHz - 11th Gen CPU Win 11 Pro (Renewed)
By Dell
$559.00
Dell 2021 OptiPlex 7090 Ultra Desktop - Intel Core i7 11th Gen - i7-1185G7 - Quad Core 4.4Ghz - 256GB SSD - 16GB RAM - Windows 10 Pro (Renewed)
Dell 2021 OptiPlex 7090 Ultra Desktop - Intel Core i7 11th Gen - i7-1185G7 - Quad Core 4.4Ghz - 256GB SSD - 16GB RAM - Windows 10 Pro (Renewed)
By Dell
$750.00
Dell OptiPlex 7000 7090 Ultra Desktop (2021) | Core i7-2TB HDD - 8GB RAM | 4 Cores @ 4.4 GHz - 11th Gen CPU Win 11 Pro (Renewed)
Dell OptiPlex 7000 7090 Ultra Desktop (2021) | Core i7-2TB HDD - 8GB RAM | 4 Cores @ 4.4 GHz - 11th Gen CPU Win 11 Pro (Renewed)
By Dell
$599.00
2021 Dell OptiPlex 7090 Ultra Desktop - Intel Core i3 11th Gen - i3-1115G4 - Dual Core 4.1Ghz - 256GB SSD - 8GB RAM - Windows 10 Pro (Renewed)
2021 Dell OptiPlex 7090 Ultra Desktop - Intel Core i3 11th Gen - i3-1115G4 - Dual Core 4.1Ghz - 256GB SSD - 8GB RAM - Windows 10 Pro (Renewed)
By Dell
$489.00

Dell Optiplex 7090 Ultra Motherboard

Here is the photo or diagram of the Dell Optiplex 7090 Ultra system board.

Dell Optiplex 7090 Ultra Motherboard
Source: Dell
Dell Optiplex 7090 Ultra image

Dell Optiplex 7090 Ultra: Key Features

The world’s most flexible modular all-in-one experience for a streamlined workspace and productivity with built-in AI from Dell Optimizer. With the 7090 Ultra get more of everything, even desk space. Now featuring 11th Gen Intel® processors.
