Dell Optiplex 7070 Ultra Specs

Here's what you need to know about Dell Optiplex 7070 Ultra Specs, including price, processors, memory, graphics, storage, ports, and more.

BY September 19, 2019 01:33 pm
Dell Optiplex 7070 Ultra Specs

The 2019 Dell Optiplex 7070 Ultra features 25W 8th Generation Intel Whiskey Lake dual-core Intel Core i3-8145U up to a 25W quad-core Intel Core i7-8665U with a boost speed up to 4.80 GHz. The Intel Whiskey Lake PCH-LP Chipset motherboard inside Dell Optiplex 7070 Ultra has two memory slots that support up to 64GB of 2400MHz dual-channel DDR4 memory.

What's New in Dell Optiplex 7070 Ultra

Here's what you need to know about the Dell Optiplex 7070 Ultra.

  • Intel Whiskey Lake PCH-LP Chipset.
  • 8th Gen Intel Whiskey Lake Processors.
  • Up to Intel® Core™ i7-8665U (4C/8T, 1.90 → 4.80 GHz, 8MB SmartCache, 25W)
  • Up to 64GB 2400 MHz dual-channel DDR4 memory
  • Up to 1TB PCIe Gen 3 x4 NVMe SSD.
  • Up to 2TB 2.5" HDD.
  • 65W Power Adapter.
  • Up to Wi-Fi 6 and Bluetooth 5
  • More Features
    • Up to two display outputs (2 x USB-C Alt-Mode).

Dell Optiplex 7070 Ultra Full Specifications

Dell Optiplex 7070 Ultra image
Dell Optiplex 7070 Ultra
Compare

Availability

Released2019
Release InfoAnnounced on September 18, 2019.
Generations

Exterior

Dell Optiplex 7070 Ultra
Dimensions3.78” x 10.09” x 0.78” (96.1 x 256.2 x 19.7 mm)
WeightStarting at 1.16 lb (0.525 kg)
Colors
Black
Keyboard and Trackpad
  • Dell Pro Wireless Keyboard and Mouse - KM5221W - English
  • Dell KB522 Business Multimedia Keyboard (US)
  • Dell KB813 Smart Card Keyboard (US)
  • Dell KB216 Wired Keyboard English
  • No Keyboard
PortsBottom
  • 1 x USB-C
    USB 3.2 Gen 2 with DisplayPort Alt Mode and Power Delivery.
  • 2 x USB-A
    USB 3.2 Gen 2 (10 Gbps) with SmartPower On.
  • 1 x RJ45
    Gigabit Ethernet port.
  • 1 x DC-in
    4.5mm barrel type.
Left
  • 1 x USB-C
    USB 3.2 Gen 2 with DisplayPort Alt Mode.
  • 1 x USB-A
    USB 3.2 Gen 2 (10 Gbps) with PowerShare.
  • 1 x Universal Audio Port
    3.5mm jack.
Right
  • 1 x Kensington Slot
  • 1 x Security Screw Slot

Chasis

Dell Optiplex 7070 Ultra
Form FactorUltra Form Factor
Power Supply65W
4.50 mm x 2.90 mm Barrel Power Adapter.

Internal Specs

Dell Optiplex 7070 Ultra
ChipsetIntel Whiskey Lake PCH-LP Chipset
Processor
  • 8th Gen Intel® Core™ i3-8145U
    2C/4T, 2.10 → 3.90 GHz, 4MB SmartCache, 25W
  • 8th Gen Intel® Core™ i5-8265U
    4C/8T, 1.60 → 3.90 GHz, 6MB SmartCache, 25W
  • 8th Gen Intel® Core™ i5-8365U
    4C/8T, 1.60 → 4.10 GHz, 6MB SmartCache, 25W
  • 8th Gen Intel® Core™ i7-8565U
    4C/8T, 1.80 → 4.60 GHz, 8MB SmartCache, 25W
  • 8th Gen Intel® Core™ i7-8665U
    4C/8T, 1.90 → 4.80 GHz, 8MB SmartCache, 25W
Integrated Graphics
  • 8th Gen Intel® Core™ i3-8145U
    Intel® UHD Graphics 620
    24 Execution Units, 300 → 1000 MHz
  • 8th Gen Intel® Core™ i5-8265U
    Intel® UHD Graphics 620
    24 Execution Units, 300 → 1100 MHz
  • 8th Gen Intel® Core™ i5-8365U
    Intel® UHD Graphics 620
    24 Execution Units, 300 → 1100 MHz
  • 8th Gen Intel® Core™ i7-8565U
    Intel® UHD Graphics 620
    24 Execution Units, 300 → 1150 MHz
  • 8th Gen Intel® Core™ i7-8665U
    Intel® UHD Graphics 620
    24 Execution Units, 300 → 1150 MHz
Memory
  • Memory Slots: 2 SODIMM slots
  • Memory Type: Single or Dual Channel DDR4 Memory
  • Memory Speed:
    2400MHz
  • Memory Per Slot:
    4GB 8GB 16GB 32GB
Memory Configurations
4GB 8GB 16GB 32GB 64GB
Storage
  • Up to
    1TB
    M.2 PCIe Gen 3 x4 NVME SSD
  • Up to
    2TB
    7200 rpm 2.5" SATA Hard Drive
SlotsExpansion Slots
  • No Expansion slot.
SATA
  • 1 x SATA 3.0 FFC connector
    For 2.5-inch 7mm slim HDD/SSD.
M.2
  • 1 x M.2 2230 slot
    For WiFi and Bluetooth combo card
  • 1 x M.2 2230 slot
    For PCIe SDD.

Connectivity

Dell Optiplex 7070 Ultra
Wi-Fi
  • Qualcomm QCA61x4a
    Up to 867 Mbps Dual band 2.4 GHz/5 GHz WiFi-5 (802.11ac) Bluetooth 4.2
  • Intel AX200
    Up to 2400 Mbps Dual band 2.4 GHz/5 GHz WiFi-6 (802.11ax) Bluetooth 5.0
Bluetooth
Bluetooth 4.2 Bluetooth 5.0
EthernetIntel i219V (non-vPro) or Intel i219LM (vPro) Gigabit Ethernet controller
Speed: 10/100/1000 Mbps.

Software

Dell Optiplex 7070 Ultra
OS
  • Windows 10
    Home Pro Pro National Academic Pro National Academic
  • Ubuntu 18.04 LTS
Built-in Apps
Microsoft Office 30 Day Trial

Camera & Audio

Dell Optiplex 7070 Ultra
Audio
  • No built-in Speaker
  • Audio controller
    • Realtek ALC3204-CG
    • Intel High Definition Audio
  • External Ports
    • 1 x Universal Audio Jack
      Front

Misc

Dell Optiplex 7070 Ultra
Warranty3-Year Basic Onsite Service

Dell Optiplex 7070 Ultra Motherboard

Here is the photo or diagram of the Dell Optiplex 7070 Ultra system board.

Dell Optiplex 7070 Ultra Motherboard
Source: Dell
