Dell Inspiron 27 7775 All-in-One Specs

Here's what you need to know about Dell Inspiron 27 7775 All-in-One Specs, including price, processors, memory, graphics, storage, ports, and more.

BY June 10, 2017 09:22 am
Dell Inspiron 27 7775 All-in-One Specs

The 2017 Dell Inspiron 27 7775 All-in-One features 65W AMD "Zen" Core Architecture quad-core AMD Ryzen 3 1200 up to a 65W 8-core AMD Ryzen 7 1700 with a boost speed up to 3.70 GHz. The AMD B350 Chipset motherboard inside Dell Inspiron 27 7775 All-in-One has two memory slots that support up to 32GB of 2400MHz dual-channel DDR4 memory.

What's New in Dell Inspiron 27 7775 All-in-One

Here's what you need to know about the Dell Inspiron 27 7775 All-in-One.

  • Up to 27” FHD with Touch Monitor
    InfinityEdge FHD display.
  • 7th Generation AMD A-Series Processors.
  • Up to AMD Ryzen 7 (8C/16T, 3.00 → 3.70 GHz, 4MB L2, 16MB L3 Cache, 65W)
  • Up to AMD Radeon RX 580 with 8GB GDDR5.
  • Up to 32GB 2400MHz DDR4 memory.
  • Up to 256GB PCIe x4 NVMe SSD.
  • Up to 1TB 2.5” 7200rpm HDD.
  • Up to 330W power adapter.
  • More Features
    • HD RGB Webcam with built-in infrared Camera for Windows Hello Sign-in.
    • Built-in SD Card Reader 3-in-1.
    • Forward-firing soundbar equipped with speakers professionally tuned with Waves MaxxAudio® Pro.

Dell Inspiron 27 7775 All-in-One Full Specifications

Dell Inspiron 27 7775 All-in-One image
Dell Inspiron 27 7775 All-in-One
Compare

Availability

Released2017
Release InfoAnnounced on June 09, 2017.
Applicable Models
  • Dell Inspiron 27 7775 All-in-One
  • Dell Inspiron 27 7775 All-in-One (7th Gen AMD)
  • Dell Inspiron 27 7775 AIO
  • 2017 Inspiron 27 7000 All-in-One
  • 2017 Inspiron 27 7775 All-in-One Desktop
Generations

Display

Dell Inspiron 27 7775 All-in-One
Size27 Inches
Info
  • 27” FHD Non-Touch
    1920 x 1080 81 PPI 16:9 60Hz Anti-Glare
  • 27” FHD with Touch
    1920 x 1080 81 PPI 16:9 60Hz Anti-Glare
  • 27” UHD Non-Touch
    3840 x 2160 163 PPI 16:9 60Hz Anti-Glare

Exterior

Dell Inspiron 27 7775 All-in-One
Dimensions24.17 x 15.52 x 2.09 inches (613.80 x 394.10 x 53 mm)
Weight22.27 ~ 22.38 lb (10.10 ~ 10.15 kg)
Colors
Black
Keyboard and TrackpadKeyboard
  • Standard Dell KB216 Wired Keyboard
Mouse
  • Standard Dell MS 116 Wired Mouse
PortsLeft
  • 1 x USB-A
    USB 3.2 Gen 1 (5 Gbps) with PowerShare.
  • 1 x Headset port
    3.5mm jack.
  • 1 x SD-card slot
    Full-size SD Card Reader 3-in-1.
Rear
  • 1 x USB-C
    USB 3.2 Gen 1 (5 Gbps).
  • 5 x USB-A
    2 x USB 2.0 (480 Mbps).
    2 x USB 3.2 Gen 1 (5 Gbps)
    1 x USB 3.2 Gen 1 (5 Gbps) with PowerShare.
  • 2 x HDMI
    1 x HDMI-out port
    1 x HDMI-in port
  • 1 x Kensington security-cable slot
Bottom
  • 1 x RJ45
    Gigabit Ethernet port
  • 1 x Audio Jack
    3.5mm universal headphone jack.
  • 1 x Power Connector
    4.5mm x 2.99mm DC-in adapter port.

Chasis

Dell Inspiron 27 7775 All-in-One
Form FactorAll-in-One (27-inches)
Power Supply
  • 180W
    19.50 VDC 9.23 A
  • 330W
    19.50 VDC 16.90 A

Internal Specs

Dell Inspiron 27 7775 All-in-One
ChipsetAMD B350 Chipset
Processor
  • AMD Ryzen™ 3 1200
    4C/4T, 3.10 → 3.40 GHz, 2MB L2, 8MB L3 Cache, 65W
  • AMD Ryzen™ 5 1400
    4C/8T, 3.20 → 3.40 GHz, 2MB L2, 8MB L3 Cache, 65W
  • AMD Ryzen™ 7 1700
    8C/16T, 3.00 → 3.70 GHz, 4MB L2, 16MB L3 Cache, 65W
Integrated Graphics
  • AMD Ryzen™ 3 1200
    Not Available
  • AMD Ryzen™ 5 1400
    Not Available
  • AMD Ryzen™ 7 1700
    Not Available
Discrete Graphics
  • AMD Radeon™ RX 560 - 4GB GDDR5.
  • AMD Radeon™ RX 580 - 8GB GDDR5.
Memory
  • Memory Slots: 2 x SO-DIMM slots
  • Memory Type: Single or Dual Channel DDR4 Memory
  • Memory Speed:
    2400MHz
  • Memory Per Slot:
    4GB 8GB 16GB
  • Max Memory:
    32GB
Storage
  • Up to
    1 TB
    2.5-inch HDD
    SATA AHCI 6 Gbps.
  • Up to
    256 GB
    M.2 SSD
    PCIe Gen x4 NVMe, up to 32 Gbps.
SlotsExpansion Slots
  • No Expansion slot
SATA
  • 1 x 2.5” HDD Connector
M.2
  • 1 x M.2 2230 slot
    For WiFi and Bluetooth combo card
  • 1 x M.2 2230/2280 slot
    For NVMe PCIe x4 SSD, up to 16 Gbps.

Connectivity

Dell Inspiron 27 7775 All-in-One
Wi-FiWi-Fi 5
Up to 867 Mbps Dual band 2.4 GHz/5 GHz WiFi-5 (802.11ac) Bluetooth 4.1
Bluetooth
Bluetooth 4.1
EthernetGigabit Ethernet controller
Speed: 10/100/1000 Mbps.

Software

Dell Inspiron 27 7775 All-in-One
OS
  • Windows 10
    Home Pro
  • Ubuntu
Built-in Apps
  • Microsoft Office 30-Day Trial

Camera & Audio

Dell Inspiron 27 7775 All-in-One
Camera
  • HD RGB Webcam
    Top-mount front camera, 0.92 Megapixels (1280 x 720 FHD) at 30 fps.
  • With Windows Hello Infrared Camera
    0.30 Megapixels (640 x 480 VGA) at 30 fps.
Audio
  • 2 x Speakers (10W average)
  • 1 x Subwoofer (5W)
  • Digital array microphones
  • Audio controller: Realtek ALC3266-CG Waves MaxxAudio Pro
  • Subwoofer controller: Realtek ALC1309
  • External Ports
    • 1 x Universal Audio Jack
      Bottom
    • 1 x Headset port
      Left

Misc

Dell Inspiron 27 7775 All-in-One
Warranty1 Year Hardware Service with Onsite/In-Home Service After Remote Diagnosis
Compare with

Dell Inspiron 27 7775 All-in-One Price

Here is the latest price update for Dell Inspiron 27 7775 All-in-One.

Dell Inspiron 27 7775 All-in-One Motherboard

Here is the photo or diagram of the Dell Inspiron 27 7775 All-in-One system board.

Dell Inspiron 27 7775 All-in-One Motherboard
Source: Dell
