Dell Inspiron 24 5400 All-in-One Specs

Here's what you need to know about Dell Inspiron 24 5400 All-in-One Specs, including price, processors, memory, graphics, storage, ports, and more.

BY Evan Forrest October 02, 2020 06:33 pm

The 2020 Dell Inspiron 24 5400 All-in-One features 28W 11th Generation Intel Tiger Lake UP3 dual-core Intel Core i3-1115G4 up to a 28W quad-core Intel Core i7-1165G7 with a boost speed up to 4.70 GHz. The Integrated Chipset motherboard inside Dell Inspiron 24 5400 All-in-One has two memory slots that support up to 32GB of 2666MHz dual-channel DDR4 memory.

What's New in Dell Inspiron 24 5400 All-in-One

Here's what you need to know about the Dell Inspiron 24 5400 All-in-One.

Up to 23.8” FHD with Touch Monitor
InfinityEdge FHD display and an 8mm border.
11th Generation Intel Rocket Lake Processors.
Up to 28W Intel® Core™ i7-1165G7
4 cores/8 threads, 12MB SmartCache, up to 4.80 GHz.
Up to NVIDIA® GeForce® MX 330 with 2GB GDDR5.
Up to 32GB 2666MHz DDR4 memory.
Up to 1TB PCIe Gen 3.0 x4 NVMe SSD.
Up to 2TB 2.5” 7200rpm HDD.
Up to 130W power adapter.
More Features
- Up to FHD RGB Webcam with built-in infrared Camera for Windows Hello Sign-in.
- Built-in SD Card Reader 3.0.
- Forward-firing soundbar equipped with speakers professionally tuned with Waves MaxxAudio® Pro.

Dell Inspiron 24 5400 All-in-One Full Specifications

	Dell Inspiron 24 5400 All-in-One Compare
Availability
Released	2020
Release Info	Announced on October 02, 2020.
Pricing	$599.00 i3-1115G4 8GB 256GB M.2 Non-Touch Wi-Fi 6 $799.00 i5-1135G7 8GB 512GB M.2 Touch Wi-Fi 6 $1,179.00 i7-1165G7 16GB 512GB M.2 Touch Wi-Fi 6
Applicable Models	Dell Inspiron 24 5400 All-in-One Dell Inspiron 24 5400 All-in-One (10th Gen Intel) Dell Inspiron 24 5400 AIO 2020 Inspiron 24 5000 All-in-One 2020 Inspiron 24 5000 All-in-One Desktop
Generations	2020 Dell Inspiron 24 5400 All-in-One Current 2019 Dell Inspiron 24 5490 All-in-One Compare 2018 Dell Inspiron 24 5477 All-in-One Compare 2017 Dell Inspiron 24 5475 All-in-One Compare

Display	Dell Inspiron 24 5400 All-in-One
Size	23.8 Inches
Info	23.8” FHD Non-Touch 1920 x 1080 92 PPI 16:9 250 nits 700:1 72% NTSC 60Hz Anti-Glare 15.24W 23.8” FHD with Touch 1920 x 1080 92 PPI 16:9 250 nits 700:1 72% NTSC 60Hz Anti-Glare 15.24W

Exterior	Dell Inspiron 24 5400 All-in-One
Dimensions	21.24 x 13.85 x 1.64 inches (539.65 x 351.65 x 41.80 mm) Open Pop-Up Camera Height: 1.07" (27.36 mm)
Weight	Starting at 11.5 lb (5.2 kg) Including stand.
Colors	Silver Black
Keyboard and Trackpad	Keyboard White Dell KB216 Wired Keyboard Black Dell KB216 Wired Keyboard Mouse White Dell MS 116 Wired Mouse Black Dell MS 116 Wired Mouse
Ports	Rear 1 x USB-C USB 3.2 Gen 2 (10 Gbps). 4 x USB-A 1 x USB 2.0 (480 Mbps) with Power on/Wake-up support. 1 x USB 3.2 Gen 1 (5 Gbps). 1 x USB 3.2 Gen 1 (5 Gbps) with Power on/Wake-up support. 1 x USB 3.2 Gen 1 (5 Gbps) with PowerShare. 2 x HDMI 1 x HDMI-out 1.4 port 1 x HDMI-in 1.4 port 1 x SD-card slot Full-size SD Card Reader 3.0. 1 x RJ45 Gigabit Ethernet port. 1 x Audio Jack 3.5mm universal headphone jack. 1 x Kensington security-cable slot 1 x Power Connector 4.5mm x 2.99mm DC-in adapter port.

Chasis	Dell Inspiron 24 5400 All-in-One
Form Factor	All-in-One (23.8-inches)
Power Supply	90W 19.50 VDC 4.62 A 130W 19.50 VDC 6.70 A
Chasis Information	Stand Bipod Stand

Internal Specs	Dell Inspiron 24 5400 All-in-One
Chipset	Integrated Chipset
Processor	11th Gen Intel® Core™ i3-1115G4 2C/4T, 3.00 → 4.10 GHz, 6MB SmartCache, 28W 11th Gen Intel® Core™ i5-1135G7 4C/8T, 2.40 → 4.20 GHz, 8MB SmartCache, 28W 11th Gen Intel® Core™ i7-1165G7 4C/8T, 2.80 → 4.70 GHz, 12MB SmartCache, 28W
Integrated Graphics	11th Gen Intel® Core™ i3-1115G4 Intel® UHD Graphics 48 Execution Units, 400 → 1250 MHz 11th Gen Intel® Core™ i5-1135G7 Intel® Iris® Xe Graphics 80 Execution Units, 400 → 1300 MHz 11th Gen Intel® Core™ i7-1165G7 Intel® Iris® Xe Graphics 96 Execution Units, 400 → 1300 MHz
Discrete Graphics	Optional NVIDIA® GeForce® MX 330 - 2GB GDDR5.
Memory	Memory Slots: 2 x SO-DIMM slots Memory Type: Single or Dual Channel DDR4 Memory Memory Speed: 2666MHz Memory Per Slot: 4GB 8GB 16GB Max Memory: 32GB
Storage	Up to 2TB 2.5-inch HDD SATA AHCI 6 Gbps. Up to 1TB M.2 SSD PCIe Gen 3.0 x4 NVMe, up to 32 Gbps.
Slots	Expansion Slots No Expansion slot SATA 1 x 2.5” HDD Connector M.2 1 x M.2 2230 slot For WiFi and Bluetooth combo card 1 x M.2 2230/2242 slot For NVMe PCIe Gen 3 x4 SSD.

Connectivity	Dell Inspiron 24 5400 All-in-One
Wi-Fi	Intel 9462 Up to 433 Mbps Dual band 2.4 GHz/5 GHz WiFi-5 (802.11ac) Bluetooth 5.0 Intel AX201 Up to 2400 Mbps Dual band 2.4 GHz/5 GHz WiFi-6 (802.11ax) Bluetooth 5.1
Bluetooth	Bluetooth 5.0 Bluetooth 5.1
Ethernet	Realtek RTL8111HSD-CG PCIe Gigabit Ethernet controller Speed: 10/100/1000 Mbps.

Software	Dell Inspiron 24 5400 All-in-One
OS	Windows 11 Home Pro Pro National Academic Windows 10 Home Pro
Built-in Apps	McAfee® Small Business Security 12 Month Subscription Microsoft Office 30-Day Trial

Camera & Audio	Dell Inspiron 24 5400 All-in-One
Camera	HD RGB Webcam Top-mount front camera, 0.92 Megapixels (1280 x 720 HD) at 30 fps. Optional Full HD RGB Webcam Top-mount front camera, 2.07 Megapixels (1920 x 1080 FHD) at 30 fps. With Windows Hello Infrared Camera 0.30 Megapixels (640 x 480 VGA) at 30 fps.
Audio	2 x 2W Speakers Digital array microphones Audio controller: Realtek ALC3289-CG External Ports 1 x Universal Audio Jack Rear

Misc	Dell Inspiron 24 5400 All-in-One
Warranty	1 Year Hardware Service with Onsite/In-Home Service After Remote Diagnosis
Compare with	Dell Optiplex 5480 All-in-One Dell Optiplex 5490 All-in-One Dell Optiplex 7480 All-in-One Dell Optiplex 7490 All-in-One
